Pleated filter cartridges use a folded design that packs more surface area into the same housing size, giving you longer filter life and better dirt-holding capacity than standard spun cartridges. Sizes here run from 10" to 20", split across Standard and Jumbo formats, with micron ratings between 1 and 50 depending on how fine you need the filtration.
Brands stocked include Davey Microlene, Pentair, and Waimana Water, with several washable and reusable options alongside carbon-impregnated cartridges that tackle chlorine and taste as well as sediment. Check your housing size and required micron rating against the specifications below before you order, since cartridges only work correctly when matched to the right housing.
FAQs
What's the difference between a Standard and a Jumbo pleated cartridge?
Jumbo cartridges have a larger diameter than Standard ones, giving them more pleated surface area and a higher dirt-holding capacity. Jumbo cartridges need a Jumbo housing; they won't fit a Standard housing, so check your existing housing size first.
Can pleated cartridges be washed and reused?
Several cartridges in this range, including the Pentair Polypleated and HF Series and the Waimana pleated filters, are washable and can be rinsed clean and reused multiple times before replacement is needed. The carbon-impregnated versions are the exception here; once the carbon's spent, the cartridge needs replacing rather than cleaning.
What micron rating should I choose for sediment filtration?
Micron rating tells you the smallest particle size the cartridge will trap, so a 1 or 5 micron cartridge is going after fine grit while a 20 or 50 micron cartridge is built for coarser stuff like sand, rust flakes, and silt. Most households dealing with general sediment start around 20 microns and adjust from there based on results.
Do any of these cartridges reduce chlorine as well as sediment?
Yes, the Davey Microlene pleated carbon cartridges combine sediment filtration with chlorine and taste/odour reduction in a single cartridge, available in both 10" Jumbo and 20" Jumbo sizes.
How do I know which cartridge fits my existing housing?
Check the length and diameter markings on your current housing or cartridge, and match it to the Home Size filter (10" Standard, 10" Jumbo, 20" Standard, or 20" Jumbo) on this page. Cartridge length and diameter need to match your housing exactly for a proper seal.
